Product Introduction
The Dongfeng D9 Euro III Export Model is a high-performance, environmentally compliant compressed garbage truck designed for efficient municipal solid waste collection and transportation. Featuring a robust chassis, advanced compression system, and a 15-cubic-meter cargo capacity, this vehicle ensures reliability, durability, and operational efficiency in urban and suburban waste management scenarios. Its Euro III emission standard compliance makes it an ideal choice for regions prioritizing eco-friendly solutions.
Dongfeng D9 Model 4X2 15cbm 15000liters Compressed Garbage Truck Compression Waste Removal Truck
Compressed Garbage Truck Application Scenarios
Ideal for municipal waste collection, residential communities, industrial parks, and rural areas requiring efficient, large-scale waste compaction and transportation.
Keywords: Euro III, compressed garbage truck, 15m³ capacity, Dongfeng D9, export model.
Product Specifications
| Specification parameters | ||||
| Overall dimensions | 8370,7855,8405,7760,8310,8660, 8545,8435,8335×2500,2550 ×3250,3720,3300,3400 | Rated load capacity | 8450,8385,8070,8005,7516,7581 | |
| Gross Vehicle Weight | 18000(Kg) | ABS | Standard configuration | |
| Curb weight(kg) | 9420,9800,10289 | Front/rear suspension | 1260/2435 | |
| Approach/departure angle | 19/12(°) | Front and rear Axle Load | 6500kg/12000kg | |
| Wheelbase | 3950,4500,5000(mm) | Number of axles | 2 | |
| Maximum speed | 105(km/h) | Number of spring pieces | 8/10+7 | |
| Number of tires | 6 | Tire Size | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR | |
| Front track | 1862,1933,1949,1904,1960(mm) | Rear track | 1806,1865(mm) | |
| Volume | 12-15m3 | Transmission | 8 Speed gearbox | |
| Engine model | YCS04200-68，B6.2NS6B230 | Power (kw)/horsepower (PS) | 147/200,169/230 | |
| Displacement (ML) | 4200/6200 | Fuel | Diesel | |
| other | ||||
| Special device: box body, mainly used for the collection and transportation of urban sanitation garbage. The ABS system manufacturers, Model: Jiaozuo Borrick Control Technology Co., Ltd., JABS. Protective materials: Q235A carbon steel, Connection mode: the left and right side protection is welded to the side beam, Rear protection is replaced by special devices, The ground height of the rear special device is (mm): 450, 480. The corresponding relationship between the adopted engine model and the fuel consumption value is (L / 100km): B6.2NS6B210/26.3, CY4SK761/26.8, D4.0NS6B195/26.6, D4.5NS6B220/26.6, YCS04200-68/26.4.B6.2NS6B230/26.1. Install the driving recorder with satellite positioning function. Wheelbase (mm) 4500, 3950. Vehicle length / front suspension / wheelbase / rear suspension / rear extension (the corresponding relationship is (mm): 8650 / 1260 / 4500 / 2460 / 430; 8650/1260/4500/2890/0; 8950/1260/4500/2790/400; 8750/1260/4500/2790/200; 7960/1260/3950/2170/580, 7960/1260/3950/2550/200, 7960/1260/3950/2450/300; 8110/1260/3950/2500/400; 7910 / 1260 / 3950 / 2500 / 200. Optional rear flip style (bucket, bucket, full seal, swing arm, etc.) and top look. Install the fuel tank, battery, urea tank and gas reservoir on the optional side. Select the position of electric control box of multichannel valve of hydraulic fuel tank, select the new wheel cover style, select the rear flip mechanism style and cylinder installation mode. | ||||
Optional Equipment
Product Details
About Us
We are located in Suizhou City,Hubei Province,China
Welcome to the factory for inspection. You can fly to Wuhan Tianhe Airport, and our company will arrange a special car to pick you up.
Yes. We have professional R&D team, we can produce the product exactly according to your requirements.
We can provide various certifications associate. Such as ISO9000, CCC,SGS, TUV, E-Mark, EU.
T/T& L/C are preferred.
