Qingling Isuzu M100 120HP 4.17m Single-Row Box Light Truck Export Product Page
Product Overview
The Qingling Isuzu M100 is a highly efficient and reliable urban logistics light truck, equipped with Isuzu's advanced powertrain system. It offers excellent fuel economy and load capacity, making it suitable for various applications including express delivery, supermarket distribution, and cold chain transportation.
Detailed Specifications
1. Basic Parameters
- Brand: Qingling Isuzu
- Model: M100 Single-Row Box Light Truck
- Drive Configuration: 4×2 Rear-Wheel Drive
- Wheelbase (mm)**: 3360
- Overall Dimensions (L×W×H, mm)**: 5995×2150×2950
- Cargo Box Dimensions (L×W×H, mm): 4170×2050×2100
- Cargo Volume (m³): 12-14
- Curb Weight (kg): 2490
- Rated Load Capacity (kg): 1495
- Gross Vehicle Weight (kg): 4495
2. Powertrain
- Engine Model: Isuzu 4KH1
- Engine Type: Inline 4-Cylinder, Turbocharged, High-Pressure Common Rail Diesel
- Displacement (L): 2.999
- Max Power (kW/HP): 88/120
- Max Torque (N·m): 290
- Fuel Type: Diesel
- Emission Standard: China VI/Euro VI (Customizable)
- Transmission: 5-Speed Manual
3. Chassis & Suspension
- Front Axle: Forged I-Beam, Independent Suspension
- Rear Axle: Integral Stamped Welded Axle, Leaf Spring Suspension (5+2 Layers)
- Braking System: Front Disc + Rear Drum with ABS
- Tire Specification: 7.00R16LT 8PR
4. Cab Features
- Seating Capacity**: 3 Persons
- Air Conditioning**: Standard
- Steering: Hydraulic Power Steering
- Instrument Panel: Digital LCD Display
- Entertainment System: Optional Radio/USB Interface
- Other Features: Power Windows, Central Locking, Adjustable Seats
Pricing & Trade Terms
- FOB Price: USD 28,500 - 32,000 (Adjustable based on configuration & order quantity)
- Main Ports of Shipment: Shanghai Port, Guangzhou Port, Tianjin Port (Negotiable)
- MOQ: 1 Unit (Sample orders accepted)
- Payment Terms: T/T (30% deposit, 70% before shipment), L/C
- Delivery Lead Time: 15-30 Days (Stock/Customized)
After-Sales Service
- Warranty Period: 2 Years or 50,000 KM (Whichever comes first)
- Global Service Network: 500+ service centers worldwide for professional maintenance & technical support
- Spare Parts Supply: Genuine parts available globally for quick repairs
- Technical Support: 24/7 online customer service + localized after-sales teams
Applications
✅ Urban Logistics: Express delivery, supermarket distribution
✅ Cold Chain Transport: Refrigerated box option available
✅ E-Commerce Freight: Large cargo space for efficient loading/unloading
✅ Special Vehicle Modification: Customizable body types (e.g., flatbed, wing van)
Why Choose Qingling Isuzu M100?
✔ Isuzu Core Powertrain – Reliable and durable with low failure rate
✔ Compliant Large Space – 4.17m cargo box for superior loading capacity
✔ Ultra-Low Fuel Consumption – Only 8-10L per 100km, reducing operational costs
✔ Global After-Sales Support – Professional service with genuine parts availability
(Note: Specifications and pricing are subject to market adjustments. Please refer to the latest contract for details.)
